- 2.4g wi-fi transmission rate : 286.5Mbps
- type : Wireless
- wifi supported frequency : 2.4G, 5 G
- with modem function : No
- Brand : YOONGWIN
- Antennas : built-in antennas
- Encryption Type : WPA2, WPA2-PSK, WPA3, WPA-PSK, WPA
- lan ports : 0
- products status : New
- standards and protocols : WIFI 6
- Model : YW-KP-CC-500
- Solution : MT5710-CN + SKI.WB800D80S
- Memory : 1 Gb
- Flash : 1 Gb
- Dimensions : 81.6*81.6*37 mm
- Total weight : 133g
- Battery : 3300mAh
- Power supply specification : Type-C 5V/2A
- 2.4G/5GHz : Select one
- Maximum Number of Accesses : 16
Product Description
Product Detail
Product Features
1、Wide frequency band, fast internet access
Maximum theoretical rate:
NR: DL 226Mbps / UL 120Mbps
LTE: DL 200Mbps / UL 100 Mbps
2、5G module, unrestrained
Supports 4G LTE and 5G NR to achieve differentiated network services.
3、Supports Wi-Fi6, faster and stronger
Supports Wi-Fi6 AX600, with less interference and faster internet speed.
4、Built-in battery, long battery life
Comes with a 3300mAh battery, providing up to 16 hours of battery life to meet long-term needs.
5、Three-card switching is convenient and fast
You can use the built-in patch card or card slot of the device to access the internet.
6、Scan the code to recharge and start surfing the internet immediately
Scan the QR code through WeChat to enter the mini-program for recharge, and manage the network anytime and anywhere.
7、Type-C charging, mobile and portable
Supports Type-C charging, suitable for various usage scenarios, and more flexible and convenient.
Maximum theoretical rate:
NR: DL 226Mbps / UL 120Mbps
LTE: DL 200Mbps / UL 100 Mbps
2、5G module, unrestrained
Supports 4G LTE and 5G NR to achieve differentiated network services.
3、Supports Wi-Fi6, faster and stronger
Supports Wi-Fi6 AX600, with less interference and faster internet speed.
4、Built-in battery, long battery life
Comes with a 3300mAh battery, providing up to 16 hours of battery life to meet long-term needs.
5、Three-card switching is convenient and fast
You can use the built-in patch card or card slot of the device to access the internet.
6、Scan the code to recharge and start surfing the internet immediately
Scan the QR code through WeChat to enter the mini-program for recharge, and manage the network anytime and anywhere.
7、Type-C charging, mobile and portable
Supports Type-C charging, suitable for various usage scenarios, and more flexible and convenient.
|
Hardware
|
|
|
Solution
|
MT5710-CN + SKI.WB800D80S
|
|
RAM
|
1GB
|
|
Flash
|
1GB
|
|
Network port
|
None
|
|
Interface
|
1 Type-C power interface
|
|
Button
|
1 Reset button
|
|
Indicator lights
|
1 green-orange dual-color LED system light
1 green-orange dual-color LED charging light |
|
Antennas
|
Built-in professional Wi-Fi and 5G antennas
|
|
Operating Environment
|
0~40°C, 10%～90% non-condensing
|
|
Storage Environment
|
-40~70°C, 5%～95% non-condensing
|
|
Physical Size
|
81.6*81.6*37 mm
|
|
Weight
|
133g
|
|
Battery
|
3300mAh
|
|
Power Supply
|
Type-C 5V/2A
|
|
Wi-Fi
|
||
|
Standards
|
2.4GHz
|
IEEE 802.11b/g/n/ax
|
|
5GHz
|
IEEE 802.11a/n/ac/ax
|
|
|
Supported Rates
|
802.11b
|
1/2/5.5/11Mbps
|
|
802.11a/g
|
6/9/12/18/24/36/48/54Mbps
|
|
|
802.11n
|
MCS0~7
|
|
|
802.11ac
|
MCS0~11
|
|
|
802.11ax
|
MCS0~11
|
|
|
2.4G/5GHz: Select one
|
Maximum Rate
|
2.4GHz: 286.5Mbps
5GHz: 600.5Mbps |
|
Frequency Bands
|
2.4GHz:
HE20: CH1 to CH13
HE40: CH3 to CH11 |
|
|
5GHz:
HE20: CH36 to CH165
HE40: CH38 to CH163 HE80: CH42 to CH157 |
||
|
Wi-Fi Spatial Stream
|
1T1R
|
|
|
Channel Bandwidth
|
2.4GHz: 20/40MHz
5GHz: 20/40/80MHz
|
|
|
Maximum Number of Accesses
|
16
|
|
Celluar
|
||
|
Module
|
Model
|
MT5710-CN
|
|
Applicable region
|
Mainland China
|
|
|
Cellular frequency bands
|
LTE FDD
|
B1/3/5/8/34/38/39/40: Power Class 3
B41: Power Class 2
|
|
SA
|
n1/3/5/8/28: Power Class 3
n41/78/79: Power Class 2 |
|
|
Cellular speed
|
5G NR
|
DL 226Mbps / UL 120Mbps
|
|
LTE
|
200Mbps / UL 100Mbps
|
