- application : Indoor
- aspect ratio : 16:9
- Screen Type : Other
- warranty : 2 Years
- brightness : 600nit
- Pixels : 1.56mm
- specification : Video Wall
- use : Education, Medical Treatment, Self-Service Business
Specification
|
Specifications
|
Parameters
|
|
Display Size inch
|
135
|
|
LED Packaging
|
COB Integrated Packaging
|
|
LED Display Type
|
Flip – chip MINI, Direct – view Surface – emitting, Matte Frosted Surface
|
|
Full – screen Resolution
|
1920*1080
|
|
Pixel Pitch mm
|
1.56 Real Pixel
|
|
Display Ratio
|
16:9
|
|
Full – screen Dimensions mm
|
3000×1687.5mm
|
|
Flatness
|
< 0.1mm
|
|
Full – screen Weight KG
|
Wall-mounted 130, Mobile Bracket Floor-standing 170
|
|
Frame Material
|
Aluminum Alloy
|
|
Maintenance Method
|
Fully Front Maintenance
|
|
Pixel-by-pixel Luminance and Chrominance Calibration
|
Supported
|
|
Brightness cd/m2
|
600, Adjustable
|
|
Color Temperature
|
9300±500 K Adjustable
|
|
Contrast Ratio
|
10000:1
|
|
Horizontal Viewing Angle
|
160±10°
|
|
Vertical Viewing Angle
|
160±10°
|
|
Brightness Uniformity
|
≥98%
|
|
Chromaticity Uniformity
|
Within ±0.003Cx, Cy
|
|
Optimal Viewing Distance m
|
4.5
|
|
Power Supply Requirements
|
AC 100~240V, 50/60Hz
|
|
Maximum Power W/unit
|
≤1800
|
|
Average Power W/unit
|
≤620
|
|
Standby Power W
|
≤0.5
|
|
Frame Rate Hz
|
50/60
|
|
Refresh Rate Hz
|
≥3840
|
|
Drive Method
|
Constant Current Drive
|
|
Flash Correction Storage
|
Supported
|
|
Gray Scale Bit
|
14
|
|
Operating System
|
Google
|
|
CPU
|
Cortex A752 + A552
|
|
Memory/Storage
|
4GB DDR4 / 128GB EMMC
|
|
Interface Types
|
SPDIF1 / USB2.03 / HDMI IN2 / USB3.01 / AV IN1 / RJ451 / RF*1
|
|
WiFi
|
2.4G / 5G Dual-frequency WIFI*2
|
|
Bluetooth
|
5.1
|
|
Far-field Voice
|
4MIC
|
|
Remote Control Operation
|
Bluetooth Voice Remote Controller
|
|
Signal Input
|
HDMI / AVIN / RF
|
|
Upgrade Method
|
Firmware Upgrade
|
|
Signal Input
|
HDMI
|
|
Brightness Adjustment
|
Supported
|
|
Typical Lifetime hrs
|
≥100000
|
|
Operating Temperature Range ℃
|
-10~+45℃
|
|
Storage Temperature Range ℃
|
-20~+55℃
|
|
Operating Humidity Range RH
|
10%~60%RH Non-condensing
|
|
Storage Humidity Range RH
|
10%~65%RH Non-dew
|
|
Protection Level
|
Front IP54, Back IP53
|
Product Description
Specification
|
Specifications
|
Parameters
|
|
Display Size inch
|
162
|
|
LED Packaging
|
COB Integrated Packaging
|
|
LED Display Type
|
Flip – chip MINI, Direct – view Surface – emitting, Matte Frosted Surface
|
|
Full – screen Resolution
|
1920*1080
|
|
Dot Pitch mm
|
1.875 Real Pixels
|
|
Display Ratio
|
16:9
|
|
Full – screen Dimensions mm
|
3611*2151
|
|
Flatness
|
< 0.1mm
|
|
Full – screen Weight KG
|
Wall – mounted 180, Mobile Stand Floor – mounted 200
|
|
Frame Material
|
Aluminum Alloy
|
|
Maintenance Method
|
Fully Front Maintenance
|
|
Single – point Brightness Correction
|
Supported
|
|
Single – point Chromaticity Correction
|
Supported
|
|
White Balance Brightness cd/m2
|
≥600
|
|
Color Temperature
|
9000±500 K Adjustable
|
|
Contrast Ratio
|
10000:1
|
|
Horizontal Viewing Angle
|
160±10°
|
|
Vertical Viewing Angle
|
160±10°
|
|
Brightness Uniformity
|
≥98%
|
|
Chromaticity Uniformity
|
Within ±0.003Cx, Cy
|
|
Optimal Viewing Distance m
|
≥5
|
|
Power Supply Requirements
|
AC 110 – 220V, 50/60Hz
|
|
Maximum Active Power W/unit
|
≤2500
|
|
Average Active Power W/unit
|
≤800
|
|
Frame Change Frequency Hz
|
50/60
|
|
Refresh Frequency Hz
|
≥3840
|
|
Drive Method
|
Constant Current Drive
|
|
Flash Correction Storage
|
Available
|
|
Gray Scale Bit
|
13
|
|
Operating System
|
Standard Android 11.0 + Cocaa, Optional Windows
|
|
CPU
|
Cotex A734 + A534
|
|
Memory/Storage
|
4GB DDR4/32GB
|
|
Interface Types
|
SPDIF1/USB2.01/HDMI in2/USB3.03/Audio out1/RJ452
|
|
WiFi
|
2.4G/5G Dual – band, WIFI5 + WIFI6 Dual WiFi
|
|
Bluetooth
|
5.0
|
|
Remote Control Operation
|
Supported
|
|
One – key Power On/Off
|
Supported
|
|
Upgrade Method
|
Firmware Upgrade
|
|
Signal Input
|
HDMI
|
|
Brightness Adjustment
|
Manual
|
|
Fixing Method
|
Built – in
|
|
Rated Power
|
12Wx2
|
|
Continuous Working Time
|
≥7×24hrs, Support Continuous Uninterrupted Display
|
|
Mean Time Between Failures MTBF
|
≥10000 hours
|
|
Discrete Out – of – control Points
|
0 at Factory, ≤3PPM
|
|
Continuous Out – of – control Points
|
0
|
|
Blind Spot Rate
|
0 at Factory, ≤3PPM
|
|
Screen Temperature Rise During Operation
|
≤20 degrees
|
|
Typical Lifetime hrs
|
≥100000
|
|
Operating Temperature Range ℃
|
– 10~+45℃
|
|
Storage Temperature Range ℃
|
– 10~+55℃
|
|
Operating Humidity Range RH
|
10%~60%RH No Condensation
|
|
Storage Humidity Range RH
|
10%~65%RH No Dew Condensation
|
|
Protection Level
|
Front IP63, Back IP53
|
Product Description
